SK hynix 72L 3D NAND Analysis

Posted: May 31, 2018

SK hynix claims to have created the industry’s first-ever 72-layer 256Gb 3D NAND flash. This innovation has a block size 50% larger compared to 48-layer 3D TLC chips, it has a lower programming time (tPROG), the memory bit density, with 3.55 Gb/mm², increased 30% from 48L TLC, and it has a double-stack process integration for NAND string.

TechInsights has analyzed this part, and we are preparing to release a number of reports within the next 2 months.

We have prepared a brief that provides additional information about this product and our analysis.
