Samsung 1y LPDDR4X SDRAM (K3UH7H70AM-AGCL) 8 Gb Circuit Analysis

Availability

Published

Product Code

CAR-1909-801

Release Date

28/07/2020

Product Item Code

SAM-K3UH7H70AM-AGCL

Device Manufacturer

Samsung

Device Type

LPDDR4X

Subscription

Memory - NAND & DRAM

Channel

Memory - DRAM Circuit Analysis

Samsung 1y LPDDR4X SDRAM (K3UH7H70AM-AGCL) 8 Gb Circuit Analysis

The following is a CircuitVision Analysis report on the Samsung K3UH7H70AM-AGCL 1y 8 Gbit LPDDR4X SDRAM die found in the Samsung K3UH7H70 DDR4 SDRAM CMOS. The following report contains a full set of schematics and annotated photographs divided into the following sections:

Architectural Overview
Address Path
Data Path
Control Circuitry
Voltage Circuitry
Configuration and Test Circuitry
Symbol Definitions
Major Findings
Standard Cells
Appendix A – Signal List
