SK Hynix DTDRH682WX2 1y 8 Gb DDR4 SDRAM Circuit Analysis

Product Code
CAR-2001-802
Release Date
04/02/2021
Availability
Published
Product Item Code
HYN-DTDRH682WX2
Device Manufacturer
Hynix
Device Type
DDR4 SDRAM
Subscription
Memory - NAND & DRAM
Channel
Memory - DRAM Circuit Analysis
Report Code
CAR-2001-802
The following is a CircuitVision Analysis report on the SK Hynix DTDRH682WX2 1y 8 Gb DDR4 SDRAM. The report contains a full set of schematics and annotated photographs divided into the following sections:
  • Architectural Overview
  • Memory Array and Peripherals
  • The Data Path
  • Symbol Definitions
  • Major Findings
  • Standard Cells
  • Appendix A - Signal List
